热水 lines, boilers 和 hydronic heating
耐用 和 精确 温度计 带 刚性 连接
separable 温度计套管
坚固 钢 表壳
bi-metallic element
双 刻度 (°f 与 °c)
背面 或 底部 connected
1/2” NPT 过程连接
ASME B40.200 compliant
5 年 质保
| Dial | 3.5” (90mm), aluminum with black markings |
| Case | Steel |
| Lens | Glass |
| Ring | Steel chrome plated |
| Stem | Brass |
| Thermowell | Brass, 1/2” NPT (standard), separable |
| Movement | Bi-metallic coil |
| Pointer | Aluminum, painted black |
| Over-Range Enclosure Rating | ±25% of full scale value |
| Reset | Standard |
| Ambient Temperature | -22°F to 158°F (-30°C to 70°C) |
| Process Temperature | -22°F to 250°F (-30°C to 120°C) |
| Accuracy | ±2% of full scale |
| Enclosure Rating | IP50 |
| Warning |  Warning: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. |
