设计 以 be 应用 其中 精度 和 重复性 是 的 prime importance|用于 laboratories 和 仪器 测试 facilities
高度 精确 ±0.5% 完整 带 校准 certificate traceable 以 NIST 标准
镜面 anti-parallax 表盘
knife-edge 指针
protective 携带 和 存储 表壳 可选
ASME B40.100 compliant
CRN registered
5 年 质保
| Dial | White aluminum with black markings and mirror band for precise instrument readings |
| Case | AISI 304 SS |
| Lens | 4" (100mm): Polycarbonate 6" (150mm): Glass |
| Ring | AISI 304 SS |
| Socket | Brass or Stainless Steel |
| Connection | 1/4” NPT or 1/2” NPT standard, bottom |
| Bourdon Tube | Phosphor bronze or Stainless Steel |
| Movement | Brass or Stainless Steel |
| Pointer | Aluminum, anodized black, micrometer adjustable, knife-edge |
| Welding | Silver alloy |
| Over-Pressure Limit | 30% of full scale value |
| Working Pressure | Maximum 75% of full scale value |
| Calibration Conditions | 68°F (±5.4°F), 20°C (±3°C) for ambient and process temperatures at atmospheric pressure |
| Ambient/Process Temperature | -4°F to 150°F (-20°C to 65°C) |
| Accuracy | ±0.5% ANSI/ASME Grade 2A |
| Enclosure Rating | IP65 |
| Warning |  Warning: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. |
