residential 和 商用 swimming pools 过滤器/泵
2” (50mm) 表盘
weather 防护 黑色 ABS 塑料 表壳
黄铜 wetted parts
ASME B40.100 compliant
±3-2-3% 精度
CRN registered
5 年 质保
| Dial | 2” (50mm) white aluminum with black markings |
| Case | Weather resistant black ABS plastic case |
| Lens | Acrylic |
| Socket | Brass |
| Connection | 1/4” NPT |
| Bourdon Tube | Phosphor bronze |
| Movement | Brass |
| Pointer | Aluminum, black |
| Welding | Silver alloy |
| Over-Pressure Limit | 25% of full scale value |
| Working Pressure | Maximum 75% of full scale value |
| Ambient/Process Temperature | -40°F to 150°F (-40°C to 65°C) |
| Accuracy | ±3-2-3% ANSI/ASME Grade B |
| Enclosure Rating | IP52 |
| Warning |  Warning: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. Form more information go to www.P65Warnings.ca.gov. |
