混合型热释电传感器，金属镀膜，低噪声。
本产品已被取代，请查看此页面了解新产品。
Measurement capabilities | |
| Maximum average power | 50 mW |
| Noise equivalent power1 | 2 nW |
| Spectral range | 0.1 - 1000 μm |
| Current responsivity | 0.5 μA/W |
| Thermal frequency | 0.8 Hz |
| Voltage responsivity2 | 25 kV/W |
| Feedback resistor | 100 GΩ |
| Supply voltage | ±5 V |
Physical characteristics | |
| Aperture diameter | 3 mm |
| Absorber | MT |
| Dimensions | 9.1Ø x 6.4D mm |
| Weight | 0.001 kg |
| Package | TO5 |
