WiFi 6E 就绪；支持以太网供电（PoE）；两年质保
主要特点
WiFi 6E 就绪
支持以太网供电（PoE）
两年质保
| Attenuation Step Size (dB) | 0.05 |
| Number of individually controlled RF chains | 4 |
| Operating Frequency (MHz) | 100 – 8,000 |
| Attenuation Range (dB) | 0 – 120 |
| Impedance (Ω) | 50 |
| IP3 Input (dBm) | +40 |
| Connectors | SMA Female |
| Frequency | Attenuation | Typical Accuracy |
|---|---|---|
| 100 – 8000 MHz | 3 | ± 0.2 |
| 15 | ± 0.4 | |
| 30 | ± 0.8 | |
| 45 | ± 1.2 | |
| 60 | ± 1.9 | |
| 75 | ± 2.1 | |
| 90 | ± 2.6 | |
| 105 | ± 3.4 | |
| 120 | ± 3.9 |
| Typical | Max | |
| 100 MHz | 5.5 | 6.5 |
| 2400 MHz | 6.5 | 7.6 |
| 6000 MHz | 9.8 | 11.0 |
| 8000 MHz | 11.5 | 12.5 |
| Switching Speed (μs) | 550 |
| 100 – 8000MHz | > 1 : 1 |
| Max Input RF Power (dBm) | +28 |
| Power Use (USB) (mA) | 188 |
| Power Over Ethernet | IEEE802.3at Class 2 compliant |
| Operating Temperature (°C) | 0 to 60 |
| Communication | USB (Virtual COM Port) Ethernet (Telnet & HTTP, DHCP & Static IP) |
| Interchain Isolation (Chain-to-chain isolation)(dB) | >130 |
| External Isolation (dB) | >130 |
| ECCN #: | EAR99 |
| HTS #: | 9030.40.90.00 |
