型号：Weschler
直流 面板 仪器 类型 351 (3-1/2”), 371 (4-1/2″) 圆形 和 矩形
Weschler NX-351, NX-371, RA-371, RX-351 与 RX-371 满足 全部 性能 要求 的 ANSI C39.1-1981 用于 圆形 和 矩形 面板 仪器. 它们 employ conventional taut band mechanisms 封闭式 在 黑色 fluted 外壳 设计 以 match appearance 的 westinghouse 开关板 仪器 和 继电器 和 其他 设备 应用 于 traditionally styled 控制 面板.
直流 面板 仪器 类型 351 (3-1/2”), 371 (4-1/2″) 圆形 和 矩形
Weschler NX-351, NX-371, RA-371, RX-351 与 RX-371 满足 全部 性能 要求 的 ANSI C39.1-1981 用于 圆形 和 矩形 面板 仪器. 它们 employ conventional taut band mechanisms 封闭式 在 黑色 fluted 外壳 设计 以 match appearance 的 westinghouse 开关板 仪器 和 继电器 和 其他 设备 应用 于 traditionally styled 控制 面板.
直流 面板 仪器 类型 351 (3-1/2”), 371 (4-1/2″) 圆形 和 矩形
Weschler NX-351, NX-371, RA-371, RX-351 与 RX-371 满足 全部 性能 要求 的 ANSI C39.1-1981 用于 圆形 和 矩形 面板 仪器. 它们 employ conventional taut band mechanisms 封闭式 在 黑色 fluted 外壳 设计 以 match appearance 的 westinghouse 开关板 仪器 和 继电器 和 其他 设备 应用 于 traditionally styled 控制 面板.
特性
高 扭矩 以 重量 比: ensures rapid, 精确 读数 带 高 damping 和 最小 frictional 效应. 便捷 以 读取 刻度: 线性 于 直流. virtually 线性 above 10% 的 全 刻度 于 交流. 自 shielding: 直流 类型 是 magnetically shielded 和 校准 为 unaffected regardless 的 material 或 thickness 的 安装 面板.
Weschler-面板-conventional Weschler-式样_listings-面板
| Item # | Model | Type | Rating | Standard Scale | Case Size |
|---|---|---|---|---|---|
| 291B554A12 | RX-351 | DC Microammeter | 50 uA | 0-50 DC Microamperes | 3-1/2" Rectangular |
| 409C534A15 | RX-351 | DC Microammeter | 80 uA | 0-80 DC Microamperes | 3-1/2" Rectangular |
| 409C534A09 | RX-351 | DC Microammeter | 100 uA | 0-100 DC Microamperes | 3-1/2" Rectangular |
| 409C534A10 | RX-351 | DC Microammeter | 150 uA | 0-150 DC Microamperes | 3-1/2" Rectangular |
| 409C534A11 | RX-351 | DC Microammeter | 200 uA | 0-200 DC Microamperes | 3-1/2" Rectangular |
| 409C534A12 | RX-351 | DC Microammeter | 300 uA | 0-300 DC Microamperes | 3-1/2" Rectangular |
| 409C534A13 | RX-351 | DC Microammeter | 500 uA | 0-500 DC Microamperes | 3-1/2" Rectangular |
| 409C534A14 | RX-351 | DC Microammeter | 800 uA | 0-800 DC Microamperes | 3-1/2" Rectangular |
| 291B554A23 | NX-351 | DC Microammeter | 50 uA | 0-50 DC Microamperes | 3-1/2" Round |
| 409C534A27 | NX-351 | DC Microammeter | 80 uA | 0-80 DC Microamperes | 3-1/2" Round |
| 409C534A21 | NX-351 | DC Microammeter | 100 uA | 0-100 DC Microamperes | 3-1/2" Round |
| 409C534A22 | NX-351 | DC Microammeter | 150 uA | 0-150 DC Microamperes | 3-1/2" Round |
| 409C534A23 | NX-351 | DC Microammeter | 200 uA | 0-200 DC Microamperes | 3-1/2" Round |
| 409C534A24 | NX-351 | DC Microammeter | 300 uA | 0-300 DC Microamperes | 3-1/2" Round |
| 409C534A25 | NX-351 | DC Microammeter | 500 uA | 0-500 DC Microamperes | 3-1/2" Round |
| 409C534A26 | NX-351 | DC Microammeter | 800 uA | 0-800 DC Microamperes | 3-1/2" Round |
| 291B290A11 | RA-371 | DC Microammeter | 50 uA | 0-50 DC Microamperes | 4-1/2" Rectangular |
| 409C569A14 | RA-371 | DC Microammeter | 80 uA | 0-80 DC Microamperes | 4-1/2" Rectangular |
| 409C569A08 | RA-371 | DC Microammeter | 100 uA | 0-100 DC Microamperes | 4-1/2" Rectangular |
| 409C569A09 | RA-371 | DC Microammeter | 150 uA | 0-150 DC Microamperes | 4-1/2" Rectangular |
| 409C569A10 | RA-371 | DC Microammeter | 200 uA | 0-200 DC Microamperes | 4-1/2" Rectangular |
| 409C569A11 | RA-371 | DC Microammeter | 300 uA | 0-300 DC Microamperes | 4-1/2" Rectangular |
| 409C569A12 | RA-371 | DC Microammeter | 500 uA | 0-500 DC Microamperes | 4-1/2" Rectangular |
| 409C569A13 | RA-371 | DC Microammeter | 800 uA | 0-800 DC Microamperes | 4-1/2" Rectangular |
| 291B290A23 | NX-371 | DC Microammeter | 50 uA | 0-50 DC Microamperes | 4-1/2" Round |
| 409C569A26 | NX-371 | DC Microammeter | 80 uA | 0-80 DC Microamperes | 4-1/2" Round |
| 409C569A20 | NX-371 | DC Microammeter | 100 uA | 0-100 DC Microamperes | 4-1/2" Round |
| 409C569A21 | NX-371 | DC Microammeter | 150 uA | 0-150 DC Microamperes | 4-1/2" Round |
| 409C569A22 | NX-371 | DC Microammeter | 200 uA | 0-200 DC Microamperes | 4-1/2" Round |
| 409C569A23 | NX-371 | DC Microammeter | 300 uA | 0-300 DC Microamperes | 4-1/2" Round |
| 409C569A24 | NX-371 | DC Microammeter | 500 uA | 0-500 DC Microamperes | 4-1/2" Round |
| 409C569A25 | NX-371 | DC Microammeter | 800 uA | 0-800 DC Microamperes | 4-1/2" Round |
| 409C531A08 | RX-351 | DC Milliammeter | 1 mA | 0-1 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A09 | RX-351 | DC Milliammeter | 1.5 mA | 0-1.5 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A10 | RX-351 | DC Milliammeter | 2 mA | 0-2 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A11 | RX-351 | DC Milliammeter | 3 mA | 0-3 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A12 | RX-351 | DC Milliammeter | 5 mA | 0-5 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A13 | RX-351 | DC Milliammeter | 8 mA | 0-8 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A14 | RX-351 | DC Milliammeter | 10 mA | 0-10 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A15 | RX-351 | DC Milliammeter | 15 mA | 0-15 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A16 | RX-351 | DC Milliammeter | 20 mA | 0-20 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A17 | RX-351 | DC Milliammeter | 30 mA | 0-30 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A18 | RX-351 | DC Milliammeter | 50 mA | 0-50 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A19 | RX-351 | DC Milliammeter | 80 mA | 0-80 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A20 | RX-351 | DC Milliammeter | 100 mA | 0-100 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A21 | RX-351 | DC Milliammeter | 150 mA | 0-150 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A22 | RX-351 | DC Milliammeter | 200 mA | 0-200 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A23 | RX-351 | DC Milliammeter | 300 mA | 0-300 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A24 | RX-351 | DC Milliammeter | 500 mA | 0-500 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A25 | RX-351 | DC Milliammeter | 800 mA | 0-800 DC Milliamperes | 3-1/2" Rectangular |
| 409C531A32 | NX-351 | DC Milliammeter | 1 mA | 0-1 DC Milliamperes | 3-1/2" Round |
| 409C531A33 | NX-351 | DC Milliammeter | 1.5 mA | 0-1.5 DC Milliamperes | 3-1/2" Round |
| 409C531A34 | NX-351 | DC Milliammeter | 2 mA | 0-2 DC Milliamperes | 3-1/2" Round |
| 409C531A35 | NX-351 | DC Milliammeter | 3 mA | 0-3 DC Milliamperes | 3-1/2" Round |
| 409C531A36 | NX-351 | DC Milliammeter | 5 mA | 0-5 DC Milliamperes | 3-1/2" Round |
| 409C531A37 | NX-351 | DC Milliammeter | 8 mA | 0-8 DC Milliamperes | 3-1/2" Round |
| 409C531A38 | NX-351 | DC Milliammeter | 10 mA | 0-10 DC Milliamperes | 3-1/2" Round |
| 409C531A39 | NX-351 | DC Milliammeter | 15 mA | 0-15 DC Milliamperes | 3-1/2" Round |
| 409C531A40 | NX-351 | DC Milliammeter | 20 mA | 0-20 DC Milliamperes | 3-1/2" Round |
| 409C531A41 | NX-351 | DC Milliammeter | 30 mA | 0-30 DC Milliamperes | 3-1/2" Round |
| 409C531A42 | NX-351 | DC Milliammeter | 50 mA | 0-50 DC Milliamperes | 3-1/2" Round |
| 409C531A43 | NX-351 | DC Milliammeter | 80 mA | 0-80 DC Milliamperes | 3-1/2" Round |
| 409C531A44 | NX-351 | DC Milliammeter | 100 mA | 0-100 DC Milliamperes | 3-1/2" Round |
| 409C531A45 | NX-351 | DC Milliammeter | 150 mA | 0-150 DC Milliamperes | 3-1/2" Round |
| 409C531A46 | NX-351 | DC Milliammeter | 200 mA | 0-200 DC Milliamperes | 3-1/2" Round |
| 409C531A47 | NX-351 | DC Milliammeter | 300 mA | 0-300 DC Milliamperes | 3-1/2" Round |
| 409C531A48 | NX-351 | DC Milliammeter | 500 mA | 0-500 DC Milliamperes | 3-1/2" Round |
| 409C531A49 | NX-351 | DC Milliammeter | 800 mA | 0-800 DC Milliamperes | 3-1/2" Round |
| 409C565A08 | RX-371 | DC Milliammeter | 1 mA | 0-1 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A09 | RX-371 | DC Milliammeter | 1.5 mA | 0-1.5 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A10 | RX-371 | DC Milliammeter | 2 mA | 0-2 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A11 | RX-371 | DC Milliammeter | 3 mA | 0-3 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A12 | RX-371 | DC Milliammeter | 5 mA | 0-5 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A13 | RX-371 | DC Milliammeter | 8 mA | 0-8 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A14 | RX-371 | DC Milliammeter | 10 mA | 0-10 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A15 | RX-371 | DC Milliammeter | 15 mA | 0-15 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A16 | RX-371 | DC Milliammeter | 20 mA | 0-20 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A17 | RX-371 | DC Milliammeter | 30 mA | 0-30 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A18 | RX-371 | DC Milliammeter | 50 mA | 0-50 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A19 | RX-371 | DC Milliammeter | 80 mA | 0-80 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A20 | RX-371 | DC Milliammeter | 100 mA | 0-100 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A21 | RX-371 | DC Milliammeter | 150 mA | 0-150 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A22 | RX-371 | DC Milliammeter | 200 mA | 0-200 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A23 | RX-371 | DC Milliammeter | 300 mA | 0-300 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A24 | RX-371 | DC Milliammeter | 500 mA | 0-500 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A25 | RX-371 | DC Milliammeter | 800 mA | 0-800 DC Milliamperes | 4-1/2" Rectangular |
| 409C565A32 | NX-371 | DC Milliammeter | 1 mA | 0-1 DC Milliamperes | 4-1/2" Round |
| 409C565A33 | NX-371 | DC Milliammeter | 1.5 mA | 0-1.5 DC Milliamperes | 4-1/2" Round |
| 409C565A34 | NX-371 | DC Milliammeter | 2 mA | 0-2 DC Milliamperes | 4-1/2" Round |
| 409C565A35 | NX-371 | DC Milliammeter | 3 mA | 0-3 DC Milliamperes | 4-1/2" Round |
| 409C565A36 | NX-371 | DC Milliammeter | 5 mA | 0-5 DC Milliamperes | 4-1/2" Round |
| 409C565A37 | NX-371 | DC Milliammeter | 8 mA | 0-8 DC Milliamperes | 4-1/2" Round |
| 409C565A38 | NX-371 | DC Milliammeter | 10 mA | 0-10 DC Milliamperes | 4-1/2" Round |
| 409C565A39 | NX-371 | DC Milliammeter | 15 mA | 0-15 DC Milliamperes | 4-1/2" Round |
| 409C565A40 | NX-371 | DC Milliammeter | 20 mA | 0-20 DC Milliamperes | 4-1/2" Round |
| 409C565A41 | NX-371 | DC Milliammeter | 30 mA | 0-30 DC Milliamperes | 4-1/2" Round |
| 409C565A42 | NX-371 | DC Milliammeter | 50 mA | 0-50 DC Milliamperes | 4-1/2" Round |
| 409C565A43 | NX-371 | DC Milliammeter | 80 mA | 0-80 DC Milliamperes | 4-1/2" Round |
| 409C565A44 | NX-371 | DC Milliammeter | 100 mA | 0-100 DC Milliamperes | 4-1/2" Round |
| 409C565A45 | NX-371 | DC Milliammeter | 150 mA | 0-150 DC Milliamperes | 4-1/2" Round |
| 409C565A46 | NX-371 | DC Milliammeter | 200 mA | 0-200 DC Milliamperes | 4-1/2" Round |
| 409C565A47 | NX-371 | DC Milliammeter | 300 mA | 0-300 DC Milliamperes | 4-1/2" Round |
| 409C565A48 | NX-371 | DC Milliammeter | 500 mA | 0-500 DC Milliamperes | 4-1/2" Round |
| 409C565A49 | NX-371 | DC Milliammeter | 800 mA | 0-800 DC Milliamperes | 4-1/2" Round |
| 409C530A08 | RX-351 | DC Ammeter - Self-Contained | 1 A | 0-1 DC Amperes | 3-1/2" Rectangular |
| 409C530A09 | RX-351 | DC Ammeter - Self-Contained | 1.5 A | 0-1.5 DC Amperes | 3-1/2" Rectangular |
| 409C530A10 | RX-351 | DC Ammeter - Self-Contained | 2 A | 0-2 DC Amperes | 3-1/2" Rectangular |
| 409C530A11 | RX-351 | DC Ammeter - Self-Contained | 3 A | 0-3 DC Amperes | 3-1/2" Rectangular |
| 409C530A12 | RX-351 | DC Ammeter - Self-Contained | 5 A | 0-5 DC Amperes | 3-1/2" Rectangular |
| 409C530A13 | RX-351 | DC Ammeter - Self-Contained | 8 A | 0-8 DC Amperes | 3-1/2" Rectangular |
| 409C530A14 | RX-351 | DC Ammeter - Self-Contained | 10 A | 0-10 DC Amperes | 3-1/2" Rectangular |
| 409C530A15 | RX-351 | DC Ammeter - Self-Contained | 15 A | 0-15 DC Amperes | 3-1/2" Rectangular |
| 409C530A16 | RX-351 | DC Ammeter - Self-Contained | 20 A | 0-20 DC Amperes | 3-1/2" Rectangular |
| 409C530A17 | RX-351 | DC Ammeter - Self-Contained | 30 A | 0-30 DC Amperes | 3-1/2" Rectangular |
| 409C530A18 | RX-351 | DC Ammeter - Self-Contained | 50 A | 0-50 DC Amperes | 3-1/2" Rectangular |
| 409C530A32 | NX-351 | DC Ammeter - Self-Contained | 1 A | 0-1 DC Amperes | 3-1/2" Round |
| 409C530A33 | NX-351 | DC Ammeter - Self-Contained | 1.5 A | 0-1.5 DC Amperes | 3-1/2" Round |
| 409C530A34 | NX-351 | DC Ammeter - Self-Contained | 2 A | 0-2 DC Amperes | 3-1/2" Round |
| 409C530A35 | NX-351 | DC Ammeter - Self-Contained | 3 A | 0-3 DC Amperes | 3-1/2" Round |
| 409C530A36 | NX-351 | DC Ammeter - Self-Contained | 5 A | 0-5 DC Amperes | 3-1/2" Round |
| 409C530A37 | NX-351 | DC Ammeter - Self-Contained | 8 A | 0-8 DC Amperes | 3-1/2" Round |
| 409C530A38 | NX-351 | DC Ammeter - Self-Contained | 10 A | 0-10 DC Amperes | 3-1/2" Round |
| 409C530A39 | NX-351 | DC Ammeter - Self-Contained | 15 A | 0-15 DC Amperes | 3-1/2" Round |
| 409C530A40 | NX-351 | DC Ammeter - Self-Contained | 20 A | 0-20 DC Amperes | 3-1/2" Round |
| 409C530A41 | NX-351 | DC Ammeter - Self-Contained | 30 A | 0-30 DC Amperes | 3-1/2" Round |
| 409C530A42 | NX-351 | DC Ammeter - Self-Contained | 50 A | 0-50 DC Amperes | 3-1/2" Round |
| 409C568A08 | RX-371 | DC Ammeter - Self-Contained | 1 A | 0-1 DC Amperes | 4-1/2" Rectangular |
| 409C568A09 | RX-371 | DC Ammeter - Self-Contained | 1.5 A | 0-1.5 DC Amperes | 4-1/2" Rectangular |
| 409C568A10 | RX-371 | DC Ammeter - Self-Contained | 2 A | 0-2 DC Amperes | 4-1/2" Rectangular |
| 409C568A11 | RX-371 | DC Ammeter - Self-Contained | 3 A | 0-3 DC Amperes | 4-1/2" Rectangular |
| 409C568A12 | RX-371 | DC Ammeter - Self-Contained | 5 A | 0-5 DC Amperes | 4-1/2" Rectangular |
| 409C568A13 | RX-371 | DC Ammeter - Self-Contained | 8 A | 0-8 DC Amperes | 4-1/2" Rectangular |
| 409C568A14 | RX-371 | DC Ammeter - Self-Contained | 10 A | 0-10 DC Amperes | 4-1/2" Rectangular |
| 409C568A15 | RX-371 | DC Ammeter - Self-Contained | 15 A | 0-15 DC Amperes | 4-1/2" Rectangular |
| 409C568A16 | RX-371 | DC Ammeter - Self-Contained | 20 A | 0-20 DC Amperes | 4-1/2" Rectangular |
| 409C568A17 | RX-371 | DC Ammeter - Self-Contained | 30 A | 0-30 DC Amperes | 4-1/2" Rectangular |
| 409C568A18 | RX-371 | DC Ammeter - Self-Contained | 50 A | 0-50 DC Amperes | 4-1/2" Rectangular |
| 409C568A32 | NX-371 | DC Ammeter - Self-Contained | 1 A | 0-1 DC Amperes | 4-1/2" Round |
| 409C568A33 | NX-371 | DC Ammeter - Self-Contained | 1.5 A | 0-1.5 DC Amperes | 4-1/2" Round |
| 409C568A34 | NX-371 | DC Ammeter - Self-Contained | 2 A | 0-2 DC Amperes | 4-1/2" Round |
| 409C568A35 | NX-371 | DC Ammeter - Self-Contained | 3 A | 0-3 DC Amperes | 4-1/2" Round |
| 409C568A36 | NX-371 | DC Ammeter - Self-Contained | 5 A | 0-5 DC Amperes | 4-1/2" Round |
| 409C568A37 | NX-371 | DC Ammeter - Self-Contained | 8 A | 0-8 DC Amperes | 4-1/2" Round |
| 409C568A38 | NX-371 | DC Ammeter - Self-Contained | 10 A | 0-10 DC Amperes | 4-1/2" Round |
| 409C568A39 | NX-371 | DC Ammeter - Self-Contained | 15 A | 0-15 DC Amperes | 4-1/2" Round |
| 409C568A40 | NX-371 | DC Ammeter - Self-Contained | 20 A | 0-20 DC Amperes | 4-1/2" Round |
| 409C568A41 | NX-371 | DC Ammeter - Self-Contained | 30 A | 0-30 DC Amperes | 4-1/2" Round |
| 409C568A42 | NX-371 | DC Ammeter - Self-Contained | 50 A | 0-50 DC Amperes | 4-1/2" Round |
| 409C530A20 | RX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-15 DC Amperes | 3-1/2" Rectangular |
| 409C530A21 | RX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-20 DC Amperes | 3-1/2" Rectangular |
| 409C530A22 | RX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-30 DC Amperes | 3-1/2" Rectangular |
| 409C530A23 | RX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-50 DC Amperes | 3-1/2" Rectangular |
| 409C530A24 | RX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-80 DC Amperes | 3-1/2" Rectangular |
| 409C530A25 | RX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-100 DC Amperes | 3-1/2" Rectangular |
| 409C530A26 | RX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-150 DC Amperes | 3-1/2" Rectangular |
| 409C530A27 | RX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-200 DC Amperes | 3-1/2" Rectangular |
| 409C530A28 | RX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-300 DC Amperes | 3-1/2" Rectangular |
| 409C530A29 | RX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-400 DC Amperes | 3-1/2" Rectangular |
| 409C530A30 | RX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-500 DC Amperes | 3-1/2" Rectangular |
| 409C530A48 | NX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-15 DC Amperes | 3-1/2" Round |
| 409C530A49 | NX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-20 DC Amperes | 3-1/2" Round |
| 409C530A50 | NX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-30 DC Amperes | 3-1/2" Round |
| 409C530A51 | NX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-50 DC Amperes | 3-1/2" Round |
| 409C530A52 | NX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-80 DC Amperes | 3-1/2" Round |
| 409C530A53 | NX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-100 DC Amperes | 3-1/2" Round |
| 409C530A54 | NX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-150 DC Amperes | 3-1/2" Round |
| 409C530A55 | NX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-200 DC Amperes | 3-1/2" Round |
| 409C530A56 | NX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-300 DC Amperes | 3-1/2" Round |
| 409C530A57 | NX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-400 DC Amperes | 3-1/2" Round |
| 409C530A58 | NX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-500 DC Amperes | 3-1/2" Round |
| 409C530A62 | NX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-600 DC Amperes | 3-1/2" Round |
| 409C530A63 | NX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-800 DC Amperes | 3-1/2" Round |
| 409C530A59 | NX-351 | DC Ammeter - Shunt Rated | 50 mV | 0-1000 DC Amperes | 3-1/2" Round |
| 409C568A20 | RX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-15 DC Amperes | 4-1/2" Rectangular |
| 409C568A21 | RX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-20 DC Amperes | 4-1/2" Rectangular |
| 409C568A22 | RX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-30 DC Amperes | 4-1/2" Rectangular |
| 409C568A23 | RX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-50 DC Amperes | 4-1/2" Rectangular |
| 409C568A24 | RX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-80 DC Amperes | 4-1/2" Rectangular |
| 409C568A25 | RX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-100 DC Amperes | 4-1/2" Rectangular |
| 409C568A26 | RX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-150 DC Amperes | 4-1/2" Rectangular |
| 409C568A27 | RX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-200 DC Amperes | 4-1/2" Rectangular |
| .409C568A28 | RX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-300 DC Amperes | 4-1/2" Rectangular |
| 409C568A29 | RX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-400 DC Amperes | 4-1/2" Rectangular |
| 409C568A30 | RX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-500 DC Amperes | 4-1/2" Rectangular |
| 409C568A62 | RX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-600 DC Amperes | 4-1/2" Rectangular |
| 409C568A63 | RX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-800 DC Amperes | 4-1/2" Rectangular |
| 409C568A48 | NX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-15 DC Amperes | 4-1/2" Round |
| 409C568A49 | NX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-20 DC Amperes | 4-1/2" Round |
| 409C568A50 | NX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-30 DC Amperes | 4-1/2" Round |
| 409C568A51 | NX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-50 DC Amperes | 4-1/2" Round |
| 409C568A52 | NX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-80 DC Amperes | 4-1/2" Round |
| 409C568A53 | NX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-100 DC Amperes | 4-1/2" Round |
| 409C568A54 | NX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-150 DC Amperes | 4-1/2" Round |
| 409C568A55 | NX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-200 DC Amperes | 4-1/2" Round |
| .409C568A56 | NX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-300 DC Amperes | 4-1/2" Round |
| 409C568A57 | NX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-400 DC Amperes | 4-1/2" Round |
| 409C568A58 | NX-371 | DC Ammeter - Shunt Rated | 50 mV | 0-500 DC Amperes | 4-1/2" Round |
| 409C534A50 | RX-351 | DC Millivoltmeter - Shunt Rated | 50 mV | Specify | 3-1/2" Rectangular |
| 409C615A08 | NX-351 | DC Millivoltmeter - Shunt Rated | 100 mV | Specify | 3-1/2" Round |
| 409C534A55 | RX-371 | DC Millivoltmeter - Shunt Rated | 50 mV | Specify | 4-1/2" Rectangular |
| 409C615A24 | NX-371 | DC Millivoltmeter - Shunt Rated | 100 mV | Specify | 4-1/2" Round |
| 409C569A50 | RX-351 | DC Millivoltmeter - Shunt Rated | 50 mV | Specify | 3-1/2" Rectangular |
| 409C622A08 | NX-351 | DC Millivoltmeter - Shunt Rated | 100 mV | Specify | 3-1/2" Round |
| 409C569A63 | RX-371 | DC Millivoltmeter - Shunt Rated | 50 mV | Specify | 4-1/2" Rectangular |
| 409C622A24 | NX-371 | DC Millivoltmeter - Shunt Rated | 100 mV | Specify | 4-1/2" Round |
| 409C534A32 | RX-351 | DC Millivoltmeter | 50 mV | 0-50 DC Millivolts | 3-1/2" Rectangular |
| 409C534A33 | RX-351 | DC Millivoltmeter | 100 mV | 0-100 DC Millivolts | 3-1/2" Rectangular |
| 409C534A34 | RX-351 | DC Millivoltmeter | 200 mV | 0-200 DC Millivolts | 3-1/2" Rectangular |
| 409C534A35 | RX-351 | DC Millivoltmeter | 500 mV | 0-500 DC Millivolts | 3-1/2" Rectangular |
| 409C534A41 | NX-351 | DC Millivoltmeter | 50 mV | 0-50 DC Millivolts | 3-1/2" Round |
| 409C534A42 | NX-351 | DC Millivoltmeter | 100 mV | 0-100 DC Millivolts | 3-1/2" Round |
| 409C534A43 | NX-351 | DC Millivoltmeter | 200 mV | 0-200 DC Millivolts | 3-1/2" Round |
| 409C534A44 | NX-351 | DC Millivoltmeter | 500 mV | 0-500 DC Millivolts | 3-1/2" Round |
| 409C569A32 | RX-371 | DC Millivoltmeter | 50 mV | 0-50 DC Millivolts | 4-1/2" Rectangular |
| 409C569A33 | RX-371 | DC Millivoltmeter | 100 mV | 0-100 DC Millivolts | 4-1/2" Rectangular |
| 409C569A34 | RX-371 | DC Millivoltmeter | 200 mV | 0-200 DC Millivolts | 4-1/2" Rectangular |
| 409C569A35 | RX-371 | DC Millivoltmeter | 500 mV | 0-500 DC Millivolts | 4-1/2" Rectangular |
| 409C569A41 | NX-371 | DC Millivoltmeter | 50 mV | 0-50 DC Millivolts | 4-1/2" Round |
| 409C569A42 | NX-371 | DC Millivoltmeter | 100 mV | 0-100 DC Millivolts | 4-1/2" Round |
| 409C569A43 | NX-371 | DC Millivoltmeter | 200 mV | 0-200 DC Millivolts | 4-1/2" Round |
| 409C569A44 | NX-371 | DC Millivoltmeter | 500 mV | 0-500 DC Millivolts | 4-1/2" Round |
| 409C532A09 | RX-351 | DC Voltmeter | 1 V | 0-1 DC Volts | 3-1/2" Rectangular |
| 409C532A10 | RX-351 | DC Voltmeter | 1.5 V | 0-1.5 DC Volts | 3-1/2" Rectangular |
| 409C532A11 | RX-351 | DC Voltmeter | 2 V | 0-2 DC Volts | 3-1/2" Rectangular |
| 409C532A12 | RX-351 | DC Voltmeter | 3 V | 0-3 DC Volts | 3-1/2" Rectangular |
| 409C532A13 | RX-351 | DC Voltmeter | 5 V | 0-5 DC Volts | 3-1/2" Rectangular |
| 409C532A14 | RX-351 | DC Voltmeter | 8 V | 0-8 DC Volts | 3-1/2" Rectangular |
| 409C532A15 | RX-351 | DC Voltmeter | 10 V | 0-10 DC Volts | 3-1/2" Rectangular |
| 409C532A16 | RX-351 | DC Voltmeter | 15 V | 0-15 DC Volts | 3-1/2" Rectangular |
| 409C532A17 | RX-351 | DC Voltmeter | 20 V | 0-20 DC Volts | 3-1/2" Rectangular |
| 409C532A18 | RX-351 | DC Voltmeter | 30 V | 0-30 DC Volts | 3-1/2" Rectangular |
| 409C532A19 | RX-351 | DC Voltmeter | 50 V | 0-50 DC Volts | 3-1/2" Rectangular |
| 409C532A20 | RX-351 | DC Voltmeter | 80 V | 0-80 DC Volts | 3-1/2" Rectangular |
| 409C532A21 | RX-351 | DC Voltmeter | 100 V | 0-100 DC Volts | 3-1/2" Rectangular |
| 409C532A22 | RX-351 | DC Voltmeter | 150 V | 0-150 DC Volts | 3-1/2" Rectangular |
| 409C532A23 | RX-351 | DC Voltmeter | 200 V | 0-200 DC Volts | 3-1/2" Rectangular |
| 409C532A24 | RX-351 | DC Voltmeter | 300 V | 0-300 DC Volts | 3-1/2" Rectangular |
| 409C532A28 | RX-351 | DC Voltmeter | 400 V | 0-400 DC Volta | 3-1/2" Rectangular |
| 409C532A25 | RX-351 | DC Voltmeter | 500 V | 0-500 DC Volts | 3-1/2" Rectangular |
| 409C532A27 | RX-351 | DC Voltmeter | 600 V | 0-600 DC Volts | 3-1/2" Rectangular |
| 409C532A36 | NX-351 | DC Voltmeter | 1 V | 0-1 DC Volts | 3-1/2" Round |
| 409C532A37 | NX-351 | DC Voltmeter | 1.5 V | 0-1.5 DC Volts | 3-1/2" Round |
| 409C532A38 | NX-351 | DC Voltmeter | 2 V | 0-2 DC Volts | 3-1/2" Round |
| 409C532A39 | NX-351 | DC Voltmeter | 3 V | 0-3 DC Volts | 3-1/2" Round |
| 409C532A40 | NX-351 | DC Voltmeter | 5 V | 0-5 DC Volts | 3-1/2" Round |
| 409C532A41 | NX-351 | DC Voltmeter | 8 V | 0-8 DC Volts | 3-1/2" Round |
| 409C532A42 | NX-351 | DC Voltmeter | 10 V | 0-10 DC Volts | 3-1/2" Round |
| 409C532A43 | NX-351 | DC Voltmeter | 15 V | 0-15 DC Volts | 3-1/2" Round |
| 409C532A44 | NX-351 | DC Voltmeter | 20 V | 0-20 DC Volts | 3-1/2" Round |
| 409C532A45 | NX-351 | DC Voltmeter | 30 V | 0-30 DC Volts | 3-1/2" Round |
| 409C532A46 | NX-351 | DC Voltmeter | 50 V | 0-50 DC Volts | 3-1/2" Round |
| 409C532A47 | NX-351 | DC Voltmeter | 80 V | 0-80 DC Volts | 3-1/2" Round |
| 409C532A48 | NX-351 | DC Voltmeter | 100 V | 0-100 DC Volts | 3-1/2" Round |
| 409C532A49 | NX-351 | DC Voltmeter | 150 V | 0-150 DC Volts | 3-1/2" Round |
| 409C532A50 | NX-351 | DC Voltmeter | 200 V | 0-200 DC Volts | 3-1/2" Round |
| 409C532A51 | NX-351 | DC Voltmeter | 300 V | 0-300 DC Volts | 3-1/2" Round |
| 409C532A55 | NX-351 | DC Voltmeter | 400 V | 0-400 DC Volta | 3-1/2" Round |
| 409C532A52 | NX-351 | DC Voltmeter | 500 V | 0-500 DC Volts | 3-1/2" Round |
| 409C532A54 | NX-351 | DC Voltmeter | 600 V | 0-600 DC Volts | 3-1/2" Round |
| 409C570A09 | RX-371 | DC Voltmeter | 1 V | 0-1 DC Volts | 4-1/2" Rectangular |
| 409C570A10 | RX-371 | DC Voltmeter | 1.5 V | 0-1.5 DC Volts | 4-1/2" Rectangular |
| 409C570A11 | RX-371 | DC Voltmeter | 2 V | 0-2 DC Volts | 4-1/2" Rectangular |
| 409C570A12 | RX-371 | DC Voltmeter | 3 V | 0-3 DC Volts | 4-1/2" Rectangular |
| 409C570A13 | RX-371 | DC Voltmeter | 5 V | 0-5 DC Volts | 4-1/2" Rectangular |
| 409C570A14 | RX-371 | DC Voltmeter | 8 V | 0-8 DC Volts | 4-1/2" Rectangular |
| 409C570A15 | RX-371 | DC Voltmeter | 10 V | 0-10 DC Volts | 4-1/2" Rectangular |
| 409C570A16 | RX-371 | DC Voltmeter | 15 V | 0-15 DC Volts | 4-1/2" Rectangular |
| 409C570A17 | RX-371 | DC Voltmeter | 20 V | 0-20 DC Volts | 4-1/2" Rectangular |
| 409C570A18 | RX-371 | DC Voltmeter | 30 V | 0-30 DC Volts | 4-1/2" Rectangular |
| 409C570A19 | RX-371 | DC Voltmeter | 50 V | 0-50 DC Volts | 4-1/2" Rectangular |
| 409C570A20 | RX-371 | DC Voltmeter | 80 V | 0-80 DC Volts | 4-1/2" Rectangular |
| 409C570A21 | RX-371 | DC Voltmeter | 100 V | 0-100 DC Volts | 4-1/2" Rectangular |
| 409C570A22 | RX-371 | DC Voltmeter | 150 V | 0-150 DC Volts | 4-1/2" Rectangular |
| 409C570A23 | RX-371 | DC Voltmeter | 200 V | 0-200 DC Volts | 4-1/2" Rectangular |
| 409C570A24 | RX-371 | DC Voltmeter | 300 V | 0-300 DC Volts | 4-1/2" Rectangular |
| 409C570A25 | RX-371 | DC Voltmeter | 500 V | 0-500 DC Volts | 4-1/2" Rectangular |
| 409C570A26 | RX-371 | DC Voltmeter | 600 V | 0-600 DC Volts | 4-1/2" Rectangular |
| 409C570A36 | NX-371 | DC Voltmeter | 1 V | 0-1 DC Volts | 4-1/2" Round |
| 409C570A37 | NX-371 | DC Voltmeter | 1.5 V | 0-1.5 DC Volts | 4-1/2" Round |
| 409C570A38 | NX-371 | DC Voltmeter | 2 V | 0-2 DC Volts | 4-1/2" Round |
| 409C570A39 | NX-371 | DC Voltmeter | 3 V | 0-3 DC Volts | 4-1/2" Round |
| 409C570A40 | NX-371 | DC Voltmeter | 5 V | 0-5 DC Volts | 4-1/2" Round |
| 409C570A41 | NX-371 | DC Voltmeter | 8 V | 0-8 DC Volts | 4-1/2" Round |
| 409C570A42 | NX-371 | DC Voltmeter | 10 V | 0-10 DC Volts | 4-1/2" Round |
| 409C570A43 | NX-371 | DC Voltmeter | 15 V | 0-15 DC Volts | 4-1/2" Round |
| 409C570A44 | NX-371 | DC Voltmeter | 20 V | 0-20 DC Volts | 4-1/2" Round |
| 409C570A45 | NX-371 | DC Voltmeter | 30 V | 0-30 DC Volts | 4-1/2" Round |
| 409C570A46 | NX-371 | DC Voltmeter | 50 V | 0-50 DC Volts | 4-1/2" Round |
| 409C570A47 | NX-371 | DC Voltmeter | 80 V | 0-80 DC Volts | 4-1/2" Round |
| 409C570A48 | NX-371 | DC Voltmeter | 100 V | 0-100 DC Volts | 4-1/2" Round |
| 409C570A49 | NX-371 | DC Voltmeter | 150 V | 0-150 DC Volts | 4-1/2" Round |
| 409C570A50 | NX-371 | DC Voltmeter | 200 V | 0-200 DC Volts | 4-1/2" Round |
| 409C570A51 | NX-371 | DC Voltmeter | 300 V | 0-300 DC Volts | 4-1/2" Round |
| 409C570A52 | NX-371 | DC Voltmeter | 500 V | 0-500 DC Volts | 4-1/2" Round |
登录注册后查看更多技术资料
(产品样本 / 使用说明书 / 通讯指令 / 软件下载)
